Mobile Compactor Storage Systems

Topnotch offer Mobile compactor Storage Systems are designed in high quality.These high storage capacity racks are available in two types : Manual (Hand Push type), Mechanically operated (chain driven) system. Mobile Optimizer comes with Full Covered panel and Half Cover Panel, Find best Movable File Storage systems in Jaipur, Rajasthan, india. We are Supplying pan India.

The choice depends on the requirements and space available at customer premises. Our rail mounted racks are suitable for all kinds of storage requirements. Being a quality oriented firm, we provide best quality products with sales after service. With our vast experience in this field, we are expert solution provider in all kind of storage products.

Topnotch Mobile Storage Compactor Can Increase your Storage space by more than 50%!!

Manual Mobile Storage Compactor

Easy movement mechanism
Heavy duty tracks
Ergonomically designed handles to ensure that sliding bays can be moved effortlessly
Central Locking
Pre-coated/Powder Epoxy Coating
Sound Buffer Button
Shelf Adjustable every 40mm Height
Easy Retrieval & Reference

Mechanical Mobile Storage Compactor

Anti-tilt
Central Locking
Safety Lock
Sound Buffer Button
Pre-coated/Powder Epoxy Coating
Adjustable Shelf
Easy Retrieval & Reference
Anti-topple system for stability & safety

Why Choose Mobile Compactor Storage Systems?

A Mobile Compactor is a high-density storage system where shelving units are mounted on movable trolleys running on rails, eliminating the need for permanent aisles. This smart movement converts entire premise space into 100% usable storage, delivering up to 80% more capacity compared to traditional static racks.

✔ Optimise existing floor area
✔ Improve record management & accessibility
✔ Ensure secure locking for confidential storage
✔ Reduce clutter and rental/storage costs
✔ Adaptable to all types of files, cartons, medicines, archives, tools & spare-parts

Unit Terminology & Sizes

Code	Description	Size (H × W × D)
SFF	Single Faced Fixed Unit	2120 mm × 915 mm × 450 mm
SFM	Single Faced Mobile Unit	2120 mm × 915 mm × 450 mm
DFM	Double Faced Mobile Unit	2120 mm × 915 mm × 900 mm

Product Variants Available

Model Type	Drive Mechanism	Ideal For
Manual Push-Pull Compactor	Hand driven	Offices, small file rooms
Mechanical Chain / Gear Driven Compactor	Wheel & chain drive	Heavy-duty industrial storage
Customized Compactor Designs	Tailored	Large corporates, Govt departments
Mobile Storage Apron / Cloth Hanger Unit	Push-pull / rail	Hostels, defence & apparel industry

Standard Hand Push & Mechanical Models

Type	Models	No. of Bodies	Height	Width	Floor Width	Depth	Floor Space Required	Description
Hand Push / Mechanical	1 Bay	4 Bodies	2120 mm	915 mm	3 Ft	450 mm	9 Ft × 6 Ft = 54 sq Ft (starting area) with aisle	Starter Unit (SFF + DFM +SFM)
Hand Push / Mechanical	1 Bay	6 Bodies	2120 mm	915 mm	3 Ft	450–900 mm	12 Ft × 6 Ft = 72 sq Ft	Add-on DFM unit (SFF + DFM -2 +SFM)
Hand Push / Mechanical	1 Bay	8 Bodies	2120 mm	915 mm	3 Ft	900 mm	15 Ft × 6 Ft = 90 sq Ft	Add-on DFM unit (SFF + DFM -3 +SFM)
Hand Push / Mechanical	2 Bay	8 Bodies	2120 mm	1830 mm	6 Ft	450 mm	9 Ft × 9 Ft = 81 sq Ft	2Side by side Cabinet Starter units combined
Mechanical	3 Bay	12 Bodies	2120 mm	2745 mm	9 Ft	450 mm	9 Ft × 12 Ft = 108 sq Ft	3 Side by Side Cabinet Starter units combined
Mechanical	4 Bay	16 Bodies	2120 mm	3660 mm	12 Ft	450 mm	9 Ft × 15 Ft = 135 sq Ft	4 Side by Side Cabinet Starter units combined
Mechanical	5 Bay	20 Bodies	2120 mm	4575 mm	15 Ft	450 mm	9 Ft × 18 Ft = 162 sq Ft	5 Side by Side Cabinet Starter units combined

Why We Are Preferred Over Other Mobile Compactor Manufacturers in India

Key Features of Topnotch Mobile Compactor Storage System

Heavy-Duty Steel Construction: Manufactured using TATA/JSW CRCA sheets to ensure durability in demanding environments.
Space Optimization: Saves up to 80% floor space by eliminating fixed aisles and creating high-density storage blocks.
Smooth Mechanism: Diamond chain and cast-iron wheel system ensures effortless push-pull or mechanical movement even when fully loaded.
Modular & Expandable: Knock-down clinch-joint design supports future extension or relocation.
Anti-Tilt Safety: Built-in safety system prevents accidental toppling when units are moved.
Adjustable Shelves: 4 removable shelves per bay with 40 mm pitch adjustment — ideal for files, cartons, boxes, and instrument trays.
Center Locking System: Robust locking ensures file security and controlled access in sensitive departments.
Low Noise Movement: Rubber sound buffers offer quiet operation in libraries, offices, and labs.
Premium Finish: Epoxy polyester powder coating (40–60 microns) resists scratches, chemicals, moisture, and corrosion.

Feature	Topnotch	Local Market Products
Material	TATA/JSW CRCA	Mixed Mild Steel
Construction Method	Weldless Clinch	Welding & joints
Anti-Rust Protection	8-tank process	Basic degreasing
Finish	40–60 micron powder coat	25–30 micron coat
Mechanism	Diamond chain + CI wheel	Generic bearings
Custom Sizing & Layout	✅ Yes	❌ Limited options
Certifications (ISO, BIFMA)	✅ Yes	❌ Usually no
After-Sales / AMC	✅ Yes	❌ Rarely provided
GeM Portal Availability	✅ Yes	❌ No
