Physics Laboratory Furniture System | Modular Pedestal & Bench Units | CRCA Steel | Granite Top | Knock-Down Design | IS-Standard Compliant Laboratory Furniture

Description

The Topnotch Physics Laboratory Furniture System is a robust, modular, and safety-engineered solution designed specifically for school, college, university, and research physics laboratories. Manufactured in compliance with Indian Standards and best laboratory practices, this system combines heavy-duty CRCA steel construction, polished granite worktops, and modular knock-down architecture to deliver long-lasting performance, flexibility, and safety.

All laboratory pedestals and benches are fabricated using 0.8 mm thick TATA / JSW CRCA steel sheet (IS 513, D Grade), supported by a rigid ERW tubular frame of 30 × 30 × 1.6 mm thickness. This ensures excellent load-bearing capacity, vibration resistance, and structural stability—critical for sensitive physics experiments and instruments.

The working surface is finished with a 16–20 mm thick black granite laboratory top, machine-polished on all exposed edges to provide:

• Chemical resistance

• Heat tolerance

• Scratch resistance

• Easy cleaning and hygiene compliance

All steel components undergo an 8-tank anti-rust pretreatment process followed by Epoxy Polyester Powder Coating (40–60 microns), strictly as recommended under IS 6005:1995 (1st Revision) and IS 3618:1966 for laboratory and steel furniture. This ensures long-term corrosion protection even in humid or high-usage lab environments.

The furniture is supplied in knock-down condition, allowing easy transportation, on-site assembly, future reconfiguration, and expansion. The final laboratory layout is customized based on room size, workflow, equipment placement, and user requirements, ensuring maximum efficiency and safety.

STANDARD LAB MODELS & MODULES

1. Wall / Island Reagent Rack

• Width: 900–1500 mm

• Usage: Wall side & island benches

• Electrical: Raceway provision (without switch & wiring)

2. Base Cabinet – Drawer & Shutter Unit (Add-on Unit)

• Size: 750W × 750D × 900H mm

• Configuration: 1 Drawer + 2 Shutters

• Top: Granite

• Storage: Enclosed cabinet

3. Corner Storage Unit

• Configuration: 1 Shutter

• Internal: Storage without shelf

• Usage: Corner optimization

4. Leg Space Module

• Size: 600W × 750D × 900H mm

• Purpose: Comfortable seating & experiment handling

5. EMC – Electrical Modular Consistence

• Size: 1500W × 750D × 900H mm

• Configuration: 4 Shutter Unit

• Usage: Island bench starter / end

• Electrical: Raceway ready (without switch & wire)

6. Island Bench with Sink (End Unit)

• Size: 1500W × 750D × 900H mm

• Configuration: 4 Shutter + Valve + PP Sink

• Storage: Without internal storage

7. Sink Unit (Compact)

• Size: 750W × 750D × 900H mm

• Configuration: 2 Shutter + Valve + PP Sink

• Storage: Without shelf

---

KEY FEATURES

• Heavy-duty CRCA steel construction (TATA / JSW)

• Granite top suitable for physics experiments

• Anti-vibration design for sensitive instruments

• Integrated electrical raceway provision

• Rounded corners for user safety

• Adjustable leveller legs for uneven floors

• Modular units for easy expansion

• Knock-down supply for easy transport

• Long-life powder-coated finish

• Designed as per Indian laboratory standards

---

APPLICATIONS

• School physics laboratories

• College & university labs

• Polytechnic institutes

• Research & testing laboratories

• Government & PSU educational facilities

• Coaching institutes with practical labs

---

IDEAL FOR

• Physics practical laboratories

• Instrument-based experiments

• Educational institutions upgrading labs

• New laboratory infrastructure projects

• Retrofit & renovation of existing labs

---

WHY CHOOSE TOPNOTCH?

• Specialised manufacturer of institutional & laboratory furniture

• IS-standard compliant materials and processes

• Modular design—future-ready & scalable

• Custom layouts based on room size & workflow

• Professional drawings before execution

• Transparent estimation & BOQ support

• Trusted supplier to schools, colleges & government projects

• Reliable after-sales support

---

WHAT’S INCLUDED

• Selected laboratory furniture modules (as per layout)

• Granite tops with polished edges

• Adjustable leveller legs

• Premium hinges & hardware

• On-site assembly support

• Layout drawings & estimation (after consultation)

---

IMPORTANT NOTE – CONSULTATION & LAYOUT

Final laboratory layout, module selection, and quantities depend on:

• Room size & shape

• Number of students

• Machinery & equipment placement

• Safety clearances & workflow

We strongly recommend consulting a Topnotch Sales Representative before purchase.
Our team will:

1. Study your room dimensions

2. Propose an optimized lab layout

3. Share drawings & technical details

4. Provide a precise cost estimation
